NKTU01-10 ABB Loop Interface Cable
Description
NKTU01-10 ABB Loop Interface Cable is a specialized industrial control cable designed for use in PLC, DCS, and automated production equipment, providing stable signal transmission and reliable electrical connections for internal module and cabinet wiring. It has a fixed length of 10 feet, ideal for adjacent port connections on the same module.
| Specification | Value |
|---|---|
| Rated Voltage | 300V AC / 300V DC |
| Rated Current | 3.0 A per core |
| Contact Resistance | ≤ 20 mΩ |
| Insulation Resistance | ≥ 500 MΩ at 500V DC |
| Withstand Voltage Test | 1500V AC for 1 minute |
| Wire Gauge | 24 AWG (0.2 mm²) |
| Core Configuration | 4 cores standard |
| Operating Temperature | -20 to 80 degrees Celsius |
| Storage Temperature | -40 to 90 degrees Celsius |
| Protection Class | IP20 for cabinet internal use |
Key Features:
- Stable and reliable signal transmission for long-term industrial system operation
- Industrial-grade construction resists temperature fluctuations, mechanical vibration, and electromagnetic interference
- Standardized interface compatible with ABB control modules and terminal boards for easy installation
- Compact structure simplifies cabinet wiring and maintenance without requiring disassembly of adjacent modules
Applications:
- Power automation systems including power plants, substations, and distribution systems
- Petrochemical production automation control systems
- Metallurgy and steel production line module connections
- Water treatment and environmental protection automation systems
Related Models:
- NKTU01-15
- NKTU01-20
- NKTU01-25
- NKTU01-30
- NKTU02-10
- NKTU11-10
