PFEA113-65 Load Cell Tension Controller by ABB Precision Control
Description
PFEA113-65 Load Cell Tension Controller is a high-precision tension control unit from ABB Precision Control, designed for continuous material processing applications that require accurate, stable tension regulation.
| Specification | Value |
|---|---|
| Measurement Range | 0-200% full scale |
| Measurement Accuracy | ±0.1% full scale |
| Response Time | Less than 10 ms |
| Power Supply | 24 VDC (18-36 V wide range), 7.5 W power consumption |
| Protection Rating | IP20 (DIN rail version), IP65 (sealed version) |
| Supported Sensors | 4 load cells per unit, expandable to 12 via cascading |
| Communication Interface | Profibus-DP, RS-485, Modbus TCP |
| Operating Temperature | 0 to 55 degrees Celsius |
Key Features:
- Intelligent control algorithms with speed-linked tension, taper control, and real-time dynamic compensation for tension fluctuations
- User-friendly 2×16 character multilingual display with panel keys for one-click parameter adjustment, no PC required
- Built-in self-diagnostic system with fault monitoring, alarm triggers, and status synchronization to Profibus network
- 6 configurable analog outputs (4-20 mA/±10 V) for seamless integration with actuators like magnetic powder brakes or servo drives
Applications:
- Continuous material processing including winding, slitting, and coating lines
- Printing, film and paper production, textile yarn processing, and metal rolling operations
- High-speed production lines for lithium battery separators and photovoltaic silicon wafer cutting
Related Models:
- PFEA111-60
- PFEA112 Series
- PFEA113-20
