PFTL101A ABB Pressductor Load Cell for Industrial Weighing
Description
PFTL101A ABB Pressductor Load Cell is a high-precision weighing sensor built on ABB’s Pressductor magnetoelastic technology, designed for tension, pressure, and weight measurement in industrial settings. It uses non-contact magnetoelastic measurement to eliminate mechanical wear, ensuring long-term stability and reliability.
| Specification | Value |
|---|---|
| Rated Load | 0.2kN, 0.5kN, 1.0kN, 2.0kN (1.0kN is standard) |
| Sensitivity | 2.0 mV/V (under excitation voltage) |
| Combined Error | ±0.03% F.S. (typical) |
| Creep | ±0.02% F.S./30min |
| Temperature Effect (Compensated) | ±0.0015% F.S./degrees Celsius |
| Overload Capacity | 150% F.S. (safe) |
| Excitation Voltage | 10-15 V DC (12 V DC recommended), max 50 mA current |
| Output Signal | Base 2 mV/V; optional 4-20 mA/HART/Profibus PA (with transmitter) |
| Protection Class | IP67 |
| Operating Temperature Range | -40 to 70 degrees Celsius |
Key Features:
- Non-contact magnetoelastic measurement with no mechanical wear
- High precision and long-term stability for critical industrial applications
- Multiple output signal options to integrate with different control systems
- IP67 protection rating for use in dusty, wet, and harsh industrial environments
- Compact, rugged design with strong vibration and shock resistance
Applications:
- Tension closed-loop control in paper machines, rolling mills, coaters, and rewinding machines
- Industrial weighing systems for production lines, packaging, and logistics
- Force measurement in material testing, process control, and metal processing
- Automated production line weight monitoring and feedback control
Related Models:
- PFTL101A 0.5kN (3BSE004160R1)
- PFTL101A 1.0kN (3BSE004166R1)
- PFTL101A 2.0kN (3BSE004172R1)
- PFTL101AE磨房型 (PFTL101AE PillowBlock version)
- PFTL101AER acid-resistant version
