Printed Circuit Board IS200WEDRG1ABC GE
Description
Printed Circuit Board IS200WEDRG1ABC GE is an industrial printed circuit board designed for integration with GE control systems. No specific technical data for this model was found, but related GE IS200 series circuit boards provide reference for typical features and applications of similar products.
| Specification | Value (Typical for IS200 Series) |
|---|---|
| Compatible Control Systems | GE Mark VI, Mark VIe Speedtronic Series |
| Working Voltage | 24V DC |
| Operating Temperature Range | -30 to 70 degrees Celsius (extended ranges up to -40 to 85 degrees Celsius for some models) |
| Electromagnetic Compatibility | Meets industrial anti-interference standards |
Key Features (Typical for IS200 Series Circuit Boards):
- Industrial-grade component construction for resistance to high temperature, vibration, and electromagnetic interference
- Modular design for easy installation, integration, and maintenance, with hot-swap support for select models
- Redundant and diagnostic functions to ensure continuous system operation and quick fault detection
- Shielded critical signal paths and multi-layer PCB design for precise signal transmission
Applications (Typical for IS200 Series Circuit Boards):
- Generator excitation systems for grid voltage and frequency stabilization
- Energy control for gas turbines, steam turbines, and hydro turbines
- Industrial automation and process control in chemical, pharmaceutical, and oil and gas industries
