Resistance Temperature Detector Board GE IS200VRTDH1DAB
Description
GE IS200VRTDH1DAB Resistance Temperature Detector Board is an industrial control and automation component belonging to GE’s Mark VI Speedtronic series, designed to convert analog signals from RTD sensors into digital temperature data for precise industrial monitoring and control.
| Specification | Value |
|---|---|
| Input Voltage | 220V |
| Output Voltage | 24V DC |
| Frequency Range | 50-60Hz |
| Maximum Power | 100W |
| Power Consumption | Less than 12W |
| Channel Count | 16 channels (supports 3-wire RTD inputs) |
| A/D Conversion Resolution | 14-bit |
| Scan Speed | 40ms (25Hz) |
| Dimensions | 100mm x 50mm x 30mm |
| Weight | 200g |
| Operating Temperature | -10 to 60 degrees Celsius |
| Protection Rating | IP65 |
| Communication Interface | Supports Profibus protocol |
Key Features:
- High-precision signal conversion with 14-bit A/D resolution for accurate temperature measurement
- 16-channel design enables simultaneous monitoring of multiple temperature points
- Automatic linearization and cold end compensation to eliminate measurement errors
- Conformal coated PCB resists dust, moisture, and chemical corrosion for enhanced reliability
- Integrated LED indicators for real-time status, fault, and operation monitoring
- Wide input compatibility supports voltage and resistance signals
Applications:
- Turbine temperature control and monitoring in power generation systems
- Process control and data collection in metallurgy, petrochemical, and oil and gas industries
- Motion control for automated machinery and robotics
- Equipment temperature monitoring in manufacturing, mining, and paper processing facilities
Related Models:
- IS200VRTDH1D
- IS220PRTDH1A
- IS200SDIIH1ADB
