SB822 ABB Backup Battery Unit for Automation Equipment
Description
SB822 ABB Backup Battery Unit is a rechargeable lithium-ion battery unit designed exclusively for ABB industrial automation equipment, providing backup power to maintain device operation and prevent data loss during main power failures. It is part of ABB’s control system module series, primarily used as an external power supply for AC 800M controllers.
| Specification | Value |
|---|---|
| Model | SB822 |
| Battery Type | Lithium-ion |
| Rated Output Voltage | 3.6V |
| Maximum Output Current | 0.05A |
| Operating Temperature Range | -20 to 60 degrees Celsius; alternate range -25 to 70 degrees Celsius |
| Lithium Metal Equivalent | 0.8 grams (0.03 ounces) |
| Typical Dimensions | Length 184.5 mm, Width 76.5 mm, Height 139.5 mm; alternate dimensions Length 160 mm, Width 85 mm, Height 120 mm |
| Weight | 0.2 kg |
| Mounting Type | DIN rail |
| Protection Rating | IP20, compliant with IEC 60529 |
Key Features:
- High reliability: Quickly takes over power supply during main power failures to ensure continuous device operation
- Modular design: Facilitates easy installation and maintenance
- Includes integrated lithium-ion battery, 24V DC connector, and TK821V020 connection cable
- Low self-discharge rate: Maintains charge for extended periods
- Compact form factor: Saves panel space
Applications:
- Industrial automation: Powers ABB PLC, DCS, and other control systems
- Process control: Supports continuous operation of process control systems
- Smart buildings: Provides backup power for HVAC, lighting, and building automation systems
- Energy management: Ensures uninterrupted operation of energy management systems
- Robotics: Supports robot control systems during power outages
- Manufacturing: Maintains automation control system functionality
- Power systems: Protects power system automation equipment
- Water treatment: Ensures continuous operation of water treatment plant controls
Related Models:
- DI880
- DO880
- TB806
- TB826
- CI853K01
- PM856K01
