Schneider 140DRA84000 Modicon Relay Discrete Output Module

Description

The Schneider 140DRA84000 Modicon Relay Discrete Output Module is a dedicated I/O module designed for the Modicon Quantum automation platform. It features 16 x 1 normally open relay outputs in a standard module form factor, with a weight of less than 1 pound. Key electrical specifications include a bus current requirement of 1100 mA, 10 A, 10 millisecond surge capability, and 500 VA switching capacity. This module operates without the need for an external power supply, with a power consumption of 5.5 W plus 0.5 W per active output point. Its I/O mapping is configured as 1 output word, supporting a wide range of operating voltages: 20 to 250 VAC and 5 to 30 VDC, with reduced load current for voltages between 30 to 150 VDC. Engineered for industrial control applications, it delivers precise discrete output control, adapts to diverse voltage environments, and provides stable, reliable switching performance for automated systems. Its compact design and robust electrical ratings make it suitable for integration into medium to large-scale industrial automation setups requiring high-current switching capabilities.
