Schneider 140NOE77100 Modicon Ethernet Network TCP/IP Module

Description

The Schneider 140NOE77100 Modicon Ethernet Network TCP/IP Module is a Class B20 device designed for industrial automation system network communication. As part of the Modicon Quantum series, it delivers reliable, high-performance connectivity for diverse industrial environments.

Key technical specifications include: 10/100Mbps Ethernet communication supporting protocols such as TCP/IP, Modbus/TCP, HTTP, and SNMP; 24V DC power input with 750mA power consumption; physical dimensions of 220×100×35mm, weight of 0.345kg, IP20 protection rating, DIN rail mounting, and two Ethernet ports. Operating temperature ranges from -25 degrees Celsius to 60 degrees Celsius, with storage temperature from -40 degrees Celsius to 85 degrees Celsius, and maximum relative humidity of 95% without condensation.

Core features include a transparent mode for seamless integration without modifying existing network configurations, and redundancy support with hot backup architecture to boost system reliability. Equipped with a high-performance processor, it offers fast data processing and response speeds, plus built-in diagnostic functions to detect and report potential faults. The module supports diverse control needs with flexible input/output options, and is widely applied in power, oil and petrochemical, water treatment, and smart manufacturing industrial automation scenarios.
