Schneider 140XBP01000 Modicon 10 Slots Racks Backplane

Description

The Schneider 140XBP01000 Modicon 10 Slots Racks Backplane is a component of the Modicon Quantum series, designed for use in PLC systems to mount and connect various I/O, communication, and function modules. It features 10 slots to support integration of multiple modules, reducing the number of racks needed and optimizing space layout in control cabinets. Key electrical specifications include 24V DC input and output voltages, with power supplied uniformly via a dedicated power module through the backplane. The unit uses a high-speed parallel/serial hybrid bus (depending on system architecture), delivering low-latency, high-bandwidth communication to ensure real-time synchronization of I/O data and improve system response speed. It supports hot swapping of compatible modules (when system configuration and modules allow), enabling maintenance without system shutdown to minimize downtime. The backplane installs via standard DIN rail, with typical dimensions of 380mm x 130mm x 90mm, and has an IP20 protection rating (for use inside enclosed control cabinets). Its operating temperature range spans -25 degrees Celsius to 70 degrees Celsius, and it meets CE, UL, and other general industrial safety standards. It is compatible with CPU modules, power modules, digital I/O, analog I/O, and communication modules, offering strong flexibility for system expansion and upgrades.
