Schneider BMXAMI0410 Isolated Analog Input Module

Description

The Schneider BMXAMI0410 Isolated Analog Input Module is a 4-channel device belonging to the BMX X80 series, designed for industrial automation data acquisition. Key technical specifications include an input impedance of 10 MΩ, allowable input overload of ±90 mA, and an internal conversion resistor of 250 Ω with 0.1% accuracy and 15 ppm/C temperature coefficient. At 25 degrees Celsius, it delivers measurement errors of 0.15% of full scale for current inputs and 0.075% of full scale for voltage inputs, with temperature drift of 30 ppm/C for current and 15 ppm/C for voltage. The module features robust isolation: 1400 V DC between channels and bus, 1400 V DC between channels and ground, and 300 V DC between individual channels. It offers high measurement resolution of 0.92 microamps for current and 0.35 mV for voltage, with maximum conversion values of 0-30 mA for current and ±11.4 V for voltage. Users can configure parameters via software, including input ranges, scan cycles, fault thresholds, and alarm mechanisms to optimize performance and diagnostics. Ideal for process control, equipment monitoring, and environmental monitoring, it supports accurate capture of physical parameters like temperature, pressure, flow, and vibration in automated systems.
