T60-NO4-HKH-F8M-H6P-M8R-P6P-U6P-WXX GE T60 Universal Relay
Description
T60-NO4-HKH-F8M-H6P-M8R-P6P-U6P-WXX GE T60 Universal Relay is a multi-functional industrial relay designed for transformer management, feeder management, and motor monitoring, integrating protection, control, and diagnostic capabilities for industrial electrical systems.
| Specification | Value |
|---|---|
| Processor Architecture | ARM Cortex-M4 or higher |
| Communication Interfaces | RS485, Ethernet (100BASEFX), fiber optic; supports Modbus, IEC 61850 |
| Input/Output | Multiple digital/analog inputs, including 8 x 5A current transformer inputs |
| Protection Rating | IP65 or higher |
| Sampling Frequency | Up to 150MHz (hardware sampling) |
| Storage Capacity | Stores over 500 inspection channel data sets and 30,000 A-Scan waveforms |
| Operating Temperature Range | -20 to 70 degrees Celsius |
Key Features:
- High integration combines protection, monitoring, and control functions in a single device
- High reliability with industrial-grade components and redundant design elements like dual power modules
- Easy scalability with modular design for adding I/O modules or communication interfaces
- Strong compatibility with multiple industrial communication protocols for seamless system integration
- High-precision waveform capture via 150MHz sampling frequency for detailed device health analysis
- Multi-level alarm threshold settings for proactive fault warning
Applications:
- Power systems: substation transformer protection, feeder automation management
- Manufacturing: motor drive system monitoring, production line equipment status tracking
- Energy industry: wind/solar inverter protection, energy storage system battery management
