Terminal Board IS200STCIH2A GE Mark VIe for Control Systems
Description
ABB Ethernet Adapter Module NETA-01 is an industrial network interconnection component designed by ABB to enable seamless connectivity between legacy industrial devices and modern Ethernet systems, supporting digital transformation and production efficiency improvements.
| Specification | Value |
|---|---|
| Interface Type | 2×RJ45 Ethernet ports (10/100Mbps auto-sensing), 1×RS-485 serial port, 1×USB 2.0 (for debugging) |
| Protection Rating | IP30 |
| Operating Temperature | -25 to 70 degrees Celsius; Storage temperature -40 to 85 degrees Celsius |
| Power Supply | 24VDC (±15%), supports redundant power input |
| Installation Method | DIN rail mounting, compatible with ABB AC500/AC500-eCo series PLC and third-party standard racks |
| Dimensions | 110mm×80mm×45mm |
| Weight | Approximately 0.3kg |
| Certifications | CE, UL, cUL, Class I Div 2, IEC 62443 |
| Connection Capacity | Up to 32 devices (RS-485 port), up to 128 devices (Ethernet port) |
| Data Cache | 512KB, supports power-off data temporary storage |
Key Features:
- Multi-protocol compatibility, supports Modbus TCP/RTU, Profinet, EtherNet/IP, OPC UA (with configuration) for seamless interconnection of different brand devices
- High-speed data transmission with dual RJ45 Ethernet ports supporting 10/100Mbps auto-sensing rate
- Redundant power design with dual 24VDC input, automatic switch to backup power if main power fails
- Industrial-grade protection with wide temperature range and IP30 rating, suitable for harsh industrial environments with dust, vibration, and electromagnetic interference
- Network security certified by IEC 62443, supports VLAN division, user permission management, and data encryption
Applications:
- Automated production lines, connects PLC, robot controllers, sensors to upload real-time production data to MES systems
- Renewable energy sector, converts RS-485 signals from inverters and meters to Modbus TCP for remote monitoring in photovoltaic and wind power plants
- Smart buildings, connects HVAC, lighting, and security subsystems to BMS via OPC UA for energy optimization
- Water treatment industry, connects PLC, flow meters, and water quality analyzers to central control rooms for real-time process regulation
Related Models:
- ABB PLC Backplane TB5640-2ETH (AC500 series)
- ABB TB511-ETH (AC500 series)
- ABB TB521-ETH (AC500 series)
- ABB TB541-ETH (AC500 series)
