TM302-A01-B00-C00-D00-E08-F00-G00 PREDICTECH Monitoring Module
Description
TM302-A01-B00-C00-D00-E08-F00-G00 PREDICTECH Monitoring Module is an intelligent power distribution monitoring module, serving as a core device for modern power system management that enables closed-loop management of real-time monitoring, intelligent analysis, and precise control.
| Specification | Value |
|---|---|
| Contact Capacity | 50A/250VAC |
| Durability | 100,000 operations |
| Rated Voltage | DC 12-30V |
| Current Range | AC 0-50A |
| Temperature Range | -40 to 85 degrees Celsius |
| Communication Interfaces | RS232, RS485; expandable to 4G, Ethernet, WiFi |
| Measurement Accuracy | 0.5 class for electrical parameters; ±0.05% for analog inputs at 25 degrees Celsius |
Key Features:
- High-precision electrical parameter monitoring, covering voltage, current, power, power factor, harmonic distortion rate, and key equipment temperature points
- Intelligent control and linkage with 50A magnetic latching relay, supporting remote operation, scheduled timing, sensor-triggered actions, and alarm-linked circuit shutdown
- Comprehensive data management and analysis, including historical data storage, multi-dimensional energy consumption reports, and predictive fault alarm via trend analysis
- Wide protocol compatibility (Modbus, DL/T645, MQTT) and flexible expansion, supporting cross-platform access via mobile App and computer management platform
Applications:
- Distribution network automation monitoring for unattended substations, distributed power grid connection, and rapid fault location
- Industrial power system optimization for factory distribution management, power cost control, and critical production equipment protection
- Building and infrastructure power distribution for intelligent buildings, data center precision monitoring, and transportation hub uninterrupted power supervision
- New energy and microgrid applications for charging pile management, microgrid coordinated scheduling, and photovoltaic power station metering
