YOKOGAWA AAR181-S50 TC/RTD Input Module

Description

The YOKOGAWA AAR181-S50 TC/RTD Input Module is a specialized industrial automation component designed for temperature signal acquisition in control systems. As a standard-type module (identified by the -S suffix), it features 12 fully isolated channels to prevent cross-interference and ensure accurate signal reading. The module supports RTD input signals, including common types such as Pt100 ohm sensors, and is suitable for integration into industrial control products.

It offers flexible configuration via a range of optional suffix codes: /R8S00 adds pressure clamp terminals for RTD (model ATR8S-00); /R8S10 includes pressure clamp terminals with surge absorbers for RTD (model ATR8S-10); /R8D00 provides dual pressure clamp terminals for RTD (model ATR8D-00); /R8D10 features dual pressure clamp terminals with surge absorbers for RTD (model ATR8D-10); and /CCC01 is equipped with a MIL cable connector (model ACCC01). Additional configuration options include a version compliant with ISA standards and a temperature operating range of -20 to 70 degrees Celsius. Its isolated channel design and versatile terminal options make it ideal for reliable temperature monitoring in complex industrial environments.
