YOKOGAWA AIP830-111 Operation Keyboard

Description

The YOKOGAWA AIP830-111 Operation Keyboard is a desktop-type HIS single-loop operation keyboard designed as a flat-panel model for industrial control systems, with one keyboard compatible per desktop HIS unit. A key feature is its integrated sound function, equipped with a USB speaker that delivers enhanced, clearer audio feedback compared to standard beeps. It features 2 USB Type-A interfaces that comply with integrated USB standards: keyboard functions run on USB 2.0 full-speed bus power, while the sound function operates on USB 1.1 full-speed bus power. Powered via the PC’s USB port, it uses an input voltage of 5V ±5% and has a current consumption of 1A. Weighing 2.0kg without a VESA bracket and 2.5kg with the bracket (which requires mounting on a support with a minimum load capacity of 10kg), the keyboard has a black chassis matching Munsell color number N1.5. It operates in temperatures ranging from 5 degrees Celsius to 40 degrees Celsius, with storage and transport temperatures spanning -20 degrees Celsius to 60 degrees Celsius, and supports a humidity range of 20% to 80% RH without condensation. Classified under IEC61010-1 Installation Class I, it does not connect directly to the main power supply.
