YXU 169G Control Board ABB YT204001-KV

Description

The YXU 169G Control Board (ABB YT204001-KV) is an industrial control module categorized as an optoelectronic component, with part number IMDSO14. Designed for industrial automation systems, this board supports precise process control, data collection, processing, and control command transmission to connected equipment. It operates on a 24V DC power supply, with an allowable input range of 19.2V DC to 30V DC. Under +24V operation, it has a maximum current draw of 210/360 milliamps, with a maximum power dissipation of 5.1 watts (peak 8.6 watts). The module measures 119mm wide, 186mm high, 135mm deep, and weighs approximately 2900 grams including its base. It features a 35mm DIN rail mounting system with a slide-and-lock mechanism for quick installation and removal. Programming and configuration are supported via ABB’s Compact Control Builder or 800xA Control Builder, compatible with System 800xA 6.0.2, Compact Control Builder 6.0.0-1 and newer versions. It also supports multi-environment configuration, including enterprise model setup, control strategy configuration, system resource configuration, and user interface configuration, with compatibility for applications like Uniformance PHD, eServer, and EBM.
